Precision Lab Optical Mounts Adjustable LensLaserMirror Holders Compatible with Thorlabs & Newport
-
CNC machined from aluminum alloy 6061-T6 or 7075 (customizable)
-
Surface finish: Black or silver anodizing
-
Precision countersunk and threaded holes for secure mounting
-
Compatible with optical posts, rods, and base plates
-
Available in both metric and imperial thread standards
-
Custom sizes, hole spacing, and surface treatment accepted
Consult
Product Details：
This CNC precision-machined post base is designed for optical breadboards and laboratory mounting platforms. Manufactured from high-strength aluminum alloy and anodized for enhanced corrosion resistance, the base provides a stable and versatile solution for securely fixing optical posts, rods, and structural elements in laboratory setups.
Its compact footprint, standard hole patterns (e.g., M6, M4 or 1/4-20), and countersunk screw ports ensure excellent compatibility with a wide range of optical benches and scientific platforms. Ideal for R&D applications, testing equipment, and prototyping environments.
Key Features
Ultra-Stable – Aerospace aluminum/stainless steel, micron-level adjustment
Wide Compatibility – Fits Ø6mm/Ø12mm/Ø25mm posts (custom sizes available)
Quick Setup – Tool-free clamping, M4/M6 optical table threads
Vibration-Resistant – Low thermal drift for laser/spectroscopy applications
Technical Specifications (Comparison Table)
| Model | OM-AL6 (Aluminum) | OM-SS12 (Stainless Steel) | OM-KM25 (Kinematic Mirror Mount) |
|---|---|---|---|
| Component Fit | Lenses/Filters | Lasers/Mirrors | High-precision optics (prisms, etc.) |
| Load Capacity | 2kg | 5kg | 1kg (±0.01° adjustment) |
| Adjustment | XY translation | Z-axis lift | 6-DOF (pitch/yaw/tilt) |
| Surface Finish | Anodized | Electropolished | Anti-reflective coating |
| Post Bore | Ø6mm/8mm | Ø12mm/25mm | Ø25mm/1-inch |
| Max Temperature | 150°C | 300°C | 200°C |
Applications
Laser Systems – Beam alignment, optical path setup
Spectroscopy – Fiber coupling, grating fixation
Microscopy – CCD camera positioning, objective lens adjustment
Why Choose Us?
Rigorous QC – Vibration-tested per ISO 9001
Fast Delivery – Quick shipping for standard models (MOQ: 10pcs)
Free CAD Files – Custom optical layout drawings available
